Simplex 4100U Installation & Maintenance

H-1
System Capacity 2,000 points of addressable points, plus 2,000 points of
annunciation. Expansion Up to capacity above.
Up to 119 Addressable cards
Cabinet Size Dependent on system configuration
Cabinet Material 1.6mm Zintex
Cabinet Finish Powder coated
Cabinet Colour Cream Wrinkle
Mounting Wall mount
Mains Input 240V AC, +6%, -10%, 50Hz
Internal Power Supply 24V DC @ 9A
Standby Battery 24V sealed lead acid up 110Ah
Battery Charger 27.3V DC (nominal)
PSU Supervision Charger high/low, Battery low/fail
Temperature -5°C to 45°C
Humidity 10% to 90% RH non-condensing
Refer to Table 6-1, 6-2 for full SPS specifications.
Alarm Relay Card
F1 Alarm, 3A, 15 x 5mm, Glass Cartridge
F2 Supervisory, 3A, 15 x 5mm, Glass Cartridge
F3 Trouble, 3A, 15 x 5mm, Glass Cartridge
Fused Distribution Board (if fitted)
F1 24V Out, 1A 20 x 5mm Glass Cartridge
F2 24V Out, 1A 20 x 5mm Glass Cartridge
F3 24V Out, 1A 20 x 5mm Glass Cartridge
F4 24V Out, 1A 20 x 5mm Glass Cartridge
• WALK TEST System Test
• 4 Operator Access Levels
• Event Historical Logging
• Device selectable Alarm Verification
• Individual Zone Isolate
• Addressable device disable/enable
• Non-volatile Flash EPROM for field editable program changes
• Expansion cards firmware upgraded via download to flash EPROMs
Appendix H
4100U Specifications
General
Fuses
Firmware Features

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
