4-1
MINIPLEX transponder interface cards (TICs) allow for data and power interconnections
between the 4100 host panel and remote locations. This chapter describes the transponder
installation procedure for 4100U MINIPLEX systems.
Refer to the page number listed in this table for information on a specific topic.
Topic See Page #
Introduction to MINIPLEX Transponders
4-2
MINIPLEX System Guidelines
4-7
Configuring Cards
4-8
TIC/Riser Mounting (4100U)
4-9
TIC/Motherboard Interconnections (4100U)
4-10
RUI Wiring (4100U)
4-11
Chapter 4
Installing 4100U MINIPLEX Components
Introduction
In this Chapter
