Simplex 4100U Installation & Maintenance

6-6
This section contains explanations of fault messages that may appear on the 4100U
display when using the SPS. Heading text in the left margin shows the error message,
while the paragraph next to it describes the likely cause of the message.
There is no output voltage from the power supply. Refer to Chapters 2 and 6 for
information on power supplies.
Appears if one or more extra devices (i.e., devices that have not been configured for the
IDNet channel) are one the system. Only one message appears, regardless of the number
of extra devices found.
There is an open on the IDNet channel. A hardware reset is required to reset the fault.
Comes up during the Earth Fault Search diagnostic function. Once the search is initiated,
the front panel display indicates how far along the search process has progressed (10%,
25%… 75%), and then shows the results of the search. The result either identifies the
offending circuit or indicates that the earth fault could not be found. SPS circuits (IDNet,
NAC, and aux power) are searched. System alarm and trouble processing is suspended
during the search.
Appears when a short is detected on the IDNet channel. This status clears automatically
when the short circuit is removed.
Appears when each device on the IDNet channel has been configured, and when none of
the devices are communicating on the channel. This message does not appear if there are
no configured devices on the IDNet channel.
Occurs when the 4100 is put into a diagnostic mode and finds a device not responding, or
responding unreliably. Refer to the 4100U PC Programmer Programming Manual (574-
849) for information on how to perform this diagnostic.
Occurs when 24 V is not present on TrueAlarm devices or when TrueAlarm sensor bases
with relay driver outputs are not properly supervised or when isolator devices are in
isolation mode.
Troubleshooting on SPS
Overview
IDNet Power
Monitor Trouble
Extra Device
Class A Trouble
Earth Fault Search
Short Circuit
Channel Fail
No Answer/
Bad Answer
Output Abnormal

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
