Simplex 4100U Installation & Maintenance

11-5
The 4100U system must be kept free from faults and tested on a weekly, monthly and
annual basis to verify that it is operating correctly. The tests required by part 8 of the
standard AS1851 Maintenance of Fire Protection Equipment are detailed in the 4100U
Operator’s Manual, LT0351.
The Operator’s manual also provides detail of report printing and performing tests that are
useful for checking the system.
Maintenance

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
