All the 4100U cards and modules (pcbs) are tested and aligned in the factory before being
supplied to the customer or fitted to a FIP. The only field adjustment that may be
necessary is to set the battery charger voltage. (Note this has been set and should not
need re-adjusting).
R341 Battery Charger Voltage
Should the battery charger voltage need adjusting, the method is as follows:
1. Run the system with the batteries connected and the door closed for at least 30
minutes to allow components to "warm up" (the longer the better).
2. Calculate the required no-load battery charging voltage by taking 27.3V for
20°C and subtracting approximately 0.1V for every 3°C above 20°C, or adding
approximately 0.1V for every 3°C below 20°C.
3. With the system not in Alarm, disconnect the batteries.
4. Measure the voltage at the battery terminals and adjust to the voltage calculated
in Step 2 by turning pot R341.
5. Re-connect the batteries.
Alignment & Adjustment
Overview

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
