Simplex 4100U Installation & Maintenance

F-5
The following lists the addressable devices approved for use with IDNet and
shows current rating and numbers allowed per loop.
Device Type Operating
Current mA
Maximum
Addressable
Point On
Analogue Loop
Maximum
Addressable
Points on
Analogue Line
4090-9116
IDNet Comms Isolator
0.5
(2 with LED on)
250 40*
4090-9118
Relay IAM with T-sense
0.5
(2 with LED on)
250 40*
4090-9117
Addressable Power
Isolator
0.5
(2 with LED on)
250 40*
4090-9118
Relay IAM with T-Sense
Input
0.5
(2 with LED on)
250 40*
4090-9119
Relay IAM with
unsupervised Input
0.5
(2 with LED on)
250 40*
409-9120
6 Point I/O
0.5 250 40*
4090-9001
Supervised IAM
0.65
(2.8 with LED
on)
250 40*
4090-9101
Monitor ZAM
0.65
(2.8 with LED
on)
250 40*
4099-9032
Manual Call Point
0.65
(2.8 with LED
on)
250 40*
* Maximum allowed by AS1670.1.
The maximum specified loop/line resistance is 40Ω.
The maximum number of LEDs switched on by an IDNet in alarm is 20.
The 6 Point I/O LED is powered from the external 24V supply, not from the loop.
Note: The relays on the 6 Point I/O are not approved for switching field loads,
i.e. the contacts may only be used to switch loads within an earthed
cabinet.
Compatible Addressable Field Devices, IDNet

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
