H-2
The DC input voltage range of the following modules is 18-33Vdc. The current listed is
nominal for 24Vdc, and may be used for battery capacity calculations.
Module Name Quiescent Alarm
N/A Master Controller Assembly
(includes SPS, CPU, CPU Motherboard
with RUI I/F, Operator Interface with
LCD)
373mA 470mA
4100-6035 Alarm Relay Card 15mA 37mA
4100-3101 IDNet Module without Devices
- per device add
- with 250 devices add
75mA
0.8mA
200mA
115mA
1mA
250mA
4100-1289 64/64 Controller plus Switch LED
Modules
- no LED on
- per LED on add
- with 64 LEDs on add
20mA
3mA
210mA
3mA
210mA
4100-0620 Transponder Interface, Basic Unit 87mA 87mA
4100-0625 Transponder Interface, Local Mode 112mA 112mA
4100-6014 Network Interface Card 28mA 28mA
4100-6056 Wired Media Module 55mA 55mA
4100-6057 Fibre Optic Media Module 25mA 25mA
4100-6038 Dual RS232 Interface 132mA 132mA
Voltage & Current Ratings of Modules & Assemblies
