LC700 – User’s Guide
3.66
A/D CONVERSION
Conversion Time 20 ms/channel
Sample Rate 5 Hz
Resolution 16 bits
PRECISION AT 77ºF (25ºC):
Range: 0-5 V, 1-5 V, 0-10 V 0.1% of span (Linearity/Interference)
Range: 0-20 mA, 4-20 mA 0.12% of span (Linearity/Interference)
Range: ±10 V 0.2% of Span (Linearity/Interference)
EFFECT OF AMBIENT TEMPERATURE
Range: 0-20 mA, 4-20 mA, 0-5 V, 0-10 V 0.2% of Span/ 77 ºF (25 ºF)
Range: 10 V 0.1% of Span/ 77 ºF (25 ºF)
DIMENSIONS AND WEIGHT
Dimensions (W x D x H)
39.9 x 137.0 x 141.5 mm;
(1.57 x 5.39 x 5.57 in)
Weight 0.201 kg
CABLES
One wire 14 AWG (2 mm
2
)
Two wires 20 AWG (0.5 mm
2
)
