Chapter 3
3.1
MODULES AND ACCESSORIES
Introduction
There are several modules available for the LC700 System. Plus, this list presented here, many
other modules are being developed to adapt to a new wide range of applications in the industry of
automation and Process Control.
Note:
These modules leave the factory with a thin plastic adhesive label that must be removed after
installation of modules
Modules List
MAIN CPUs
CPU-700-C3
CPU module with 30 Kbytes of non-volatile memory for user configuration and a microcontroller of 15
MHz.
CPU-700-D3
CPU module with 28 Kbytes of non-volatile memory for user configuration and a microcontroller of 15
MHz with real time clock and remote I/O (Master).
CPU-700-D3R
CPU module with 23 Kbytes of non-volatile memory for user configuration and a microcontroller of 15
MHz with real time clock and remote I/O (Redundant Module).
CPU-700-E3
CPU module with 52 Kbytes of non-volatile memory for user configuration and a microcontroller of 15
MHz with real time clock and remote I/O (Master).
CPU-700-E3R
CPU module with 44 Kbytes of non-volatile memory for user configuration and a microcontroller of 15
MHz with real time clock and remote I/O (Redundant Module).
POWER SUPPLY
PS-AC-R AC Power Supply for IMB: input: 90 to 264 Vac or 127 to 135 Vdc .With Redundancy capability
PS-DC-R DC Power Supply for IMB: 20 to 30 Vdc. With Redundancy capability
PS302P AC AC Power Supply 90 to 264 Vac or 127 to 135 Vdc
PS302P DC DC Power Supply 20 to 30Vdc
INPUTS
M-001 2 groups of 8 24 Vdc inputs (optically isolated)
M-002 2 groups of 8 48 Vdc inputs (optically isolated)
M-003 2 groups of 8 60 Vdc inputs (optically isolated
M-004 2 groups of 8 125 Vdc inputs (optically isolated)
M-005 2 groups of 8 24 Vdc inputs (optically isolated)
M-010 2 groups of 4 120 Vac Inputs (optically isolated)
M-011 2 groups of 4 240 Vac inputs (optically isolated))
M-012 2 groups of 8 120 Vac inputs (optically isolated)
M-013 2 groups of 8 240 Vac inputs (optically isolated)
M-020 1group of 8 push-button On/Off inputs (optically isolated)
M-302 2 groups of 8 pulse inputs 0-100 Hz-24Vdc
M-303 2 groups of 8 pulse inputs 0-10 KHz- 24 Vdc
M-304 2 groups of 8 pulse inputs 0-10 KHz- AC
M-401-R 8 Voltage/Current Analog Inputs with internal Shunt Resistor (optically isolated)
M-401-DR 8 Voltage/Current Analog Inputs with internal Shunt Resistor (optically isolated)
M-402
8 Low Level Signal (TC, RTD, mV, Ω) Inputs (optically isolated)
OUTPUTS
M-101
1 group of 16 Open Collector Outputs (optically isolated)
M-102
2 groups of 8 Transistor Outputs Source ( optically isolated)
M-110
1 group of 8 120/240 Vac Outputs (optically isolated)
M-111
2 groups of 8 120/240 Vac Outputs (optically isolated)
M-120
2 groups of 4 N.O. Relay Outputs (optically isolated)
M-121
2 groups of 4 N.C. Relay Outputs (optically isolated)
