SMAR LC700 - Technical Specifications

Modules And Accessories
3.87
Technical Specifications
ARCHITECTURE
Number of outputs 4
Number of groups 1
Number of points per group 4
ISOLATION
Channel for bus Optical Isolation up to 3700 Vrms
Channel for external source 1500 Vac
INTERNAL SOURCE
Supplied by the IMB bus 5 Vdc @ 20 mA maximum
Total Maximum Dissipation 0.1 W
EXTERNAL SOURCE
In Rush Current consumption 2.3 A, 10 ms Maximum @ 24 Vdc
External source 20-30 Vdc
Maximum Current 180 mA
Power Supply Indicator Green LED
OUTPUTS
Outputs Type Single ended ( 1 ground)
Load Impedance
5 V: 2 k
Ω minimum;
10 V: 5 k
Ω minimum
20 mA: 750
Ω maximum
OUTPUTS RANGE RANGE 1 RANGE 2 RANGE 3
Voltage Output Dip
Switch OFF
1 V to 5 V 0 V to 5 V -5 V to 5 V
Voltage Output Dip
Switch ON
2 V to 10 V
0 V to 10 V -10 V to 10 V
Current Output 4 mA to 20 mA 0 mA to 20 mA 0 mA to 20 mA
A/D CONVERSION
Conversion rate 8 ms/channel
Resolution 12 bits
Precision at 77
ο
F (25
ο
C)
+/- 0,5% of span
DIMENSIONS AND WEIGHT
Dimensions (W x D x H)
39.9 x 137.0 x 141.5 mm;
(1.57 x 5.39 x 5.57 in)
Weight 0.330 kg
CABLES
One Wire 14 AWG (2 mm
2
)
Two Wires 20 AWG (0.5 mm
2
)
