SMAR LC700 - Technical Specifications

Modules And Accessories
3.57
Technical Specifications
ARCHITECTURE
Number of inputs 16
Number of groups 2
Number of points per group 8
ISOLATION
Groups are isolated individually
Optical isolation up to 5000 Vac
EXTERNAL SOURCE
Voltage source for inputs
120 Vac (M-012)
240 Vac (M-013)
Typical consumption per point 10 mA
Power Supply Indicator None
INTERNAL SOURCE
Provided by the IMB bus 5 Vdc @ 87 mA maximum
Total Maximum Dissipation 0.435 W
Power Supply Indicator Green LED
INPUTS
ON state voltage range (logic “1”)
100-140 Vac (M-012)
200-264 Vac (M-013)
OFF state voltage range (logic “0”)
0-30 Vac (M-012)
0-50 Vac (M-013)
Input Current (typical) 10 mA
Indicator of status Yellow LED
SWITCHING INFORMATION
Minimum Voltage for logic level “1”
100 Vac (M-012), 45 a 60 Hz
200 Vac (M-013), 45 a 60 Hz
Maximum Voltage for logic level “0”
30 Vac (M-012), 45 a 60 Hz
50 Vac (M-013), 45 a 60 Hz
Typical Hysteresis
70 Vac (M-012)
150 Vac (M-013)
Time from 0 to 1 5 ms
Time from 1 to 0 42 ms
DIMENSIONS AND WEIGHT
Dimensions (W x D x H)
39.9 x 137.0 x 141.5 mm;
(1.57 x 5.39 x 5.57 in)
Weight 0.300 kg
CABLES
One Wire 14 AWG (2 mm
2
)
Two Wires 20 AWG (0.5 mm
2
)
