LC700 – User’s Guide
2.22
Requeriments for LC700 Installation and Transportation
Initial Inspection
After receiving the LC700, check:
- If the model of the device corresponds to your purchase.
- If the device has not suffered external damage in the handling and/or transportation.
- The User’s Guide, Configuration Manual and the CONF700 software CD are according to the
order.
Local Conditions for Installation
Power Supply
To obtain a stable and reliable system operation, it is required a high quality energy system,
following the requirements on the table below:
Voltage Variation 90 -264 Vac
AC Power Supply
Frequency Variation 45-65 Hz
DC Power Supply
Voltage Variation 20-30 Vdc
Environment Conditions
The temperature and relative humidity in the control room should be within the ranges specified
below:
- Temperature: 0 to 60° C
- Relative Humidity: 20 to 90% RH (non condensed).
- Storage temperature: -30 to 70° C
Air Purity
It is particularly desirable to minimize the corrosive gases and other conductive particles in the air.
Operation Mechanical Conditions
The limits below must be respected in order to the LC700 operates adequately.
- Vibration Immunity: 5Hz to 2KHz, 0,4 mm pp/2,5g mounting in panel.
