SMAR LC700 - Ac Discrete Output Module

LC700 – User’s Guide
3.76
M-110 - AC Discrete Output Module
Part Number
M-110 (2 isolated groups of 4 240 Vac outputs)
Description
This Module is designed to drive relays, pilot lamps, valves and other loads up to 1A per output. It
has 2 optically isolated groups of 4 outputs. These outputs are able to switch any voltage from 20 to
240 Vac.
M-110
+5VDC
0
1
2
3
1
0
2
3
smar
smar
110/23 - 2 groups of 4 120 / 240VAC outputs
1A
2A
3A
4A
5A
6A
7A
8A
9A
10A
1B
2B
3B
4B
5B
6B
7B
8B
9B
10B
Figure 3. 49 - AC Outputs Module M-110
R
Green
IM
B
R
Yellow
ZC
F A
F B
O2A
O1A
O1B
O2B
V
cc
1A
2A
3A
4A
5A
6A
7A
8A
9A
10A
1B
2B
3B
4B
5B
6B
7B
8B
9B
10B
Figure 3. 50 - External Connection
