SMAR LC700 - Technical Specifications

Modules And Accessories
3.79
Technical Specifications
ARCHITECTURE
Number of outputs 16
Number of groups 2
Number of points per group 8
ISOLATION
Groups are isolated individually
Optical Isolation up to 2500 Vac
EXTERNAL SOURCE
Voltage source for outputs 20 a 240 Vac, 45 to 65 Hz
Maximum consumption per group 4 A
Power Supply Indicator None
Protection One fuse per group
INTERNAL SOURCE
Provided by the IMB bus 5 Vdc @ 115 mA maximum
Total Maximum Dissipation 0.575 W
Power Supply Indicator Green LED
OUTPUTS
Voltage Output 20 to 240 Vac, 45-65 Hz
Maximum Current per Output 1 A
Maximum Total Current per Group
4 A @ T
amb
0-40 ºC (32-104 ºF)
2 A @ T
amb
40-60 ºC (104-140 ºF)
Maximum Surge Current 15 A / 0.5 cycle, 1 surge per minute maximum
Status display Yellow LED
Indicator Logic When Active
Off state Voltage Leakage current
500
μA @ 100 Vac
On state voltage drop 1.5 Vac rms Maximum
Over Load Protection per Output
Should be provided externally ( fast acting
fuse rated at 1.5 times user continuous
current)
SWITCHING INFORMATION
Zero cross operation; Ton, Toff: 1/2 cycle
RC circuit for protection 62 Ω in series with 0.01 μF
DIMENSIONS AND WEIGHT
Dimensions (W x D x H)
39.9 x 137.0 x 141.5 mm;
(1.57 x 5.39 x 5.57 in)
Weight 0.330 kg
CABLES
One Wire 14 AWG (2 mm
2
)
Two Wires 20 AWG (0.5 mm
2
)
