SMAR LC700 - Technical Specifications

Modules And Accessories
3.53
Technical Specifications
ARCHITECTURE
Number of Inputs 16
Number of groups 2
Number of points per group 8
ISOLATION
Groups are isolated individually
Optical Isolation up to 5000 Vac
EXTERNAL SOURCE
Voltage Source 20 -30 Vdc
Typical consumption per group 65 mA
Power Supply Indicator Green LED
INTERNAL SOURCE
Supplied by the IMB bus 5 Vdc @ 80 mA maximum
Total Maximum Dissipation 0.4 W
Power Supply Indicator None
INPUTS
ON state voltage range (logic “1”)
0 – 5 Vdc @ Z
load
< 200 Ω
OFF state voltage range (logic “0”)
20 – 30 Vdc @ Z
load
>10 KΩ
Typical Impedance
3.9 KΩ
Status display Yellow LED
Input current per Point 7.5 mA (typical)
SWITCHING INFORMATION
Time from “0” to “1”
30 μs
Time from “1” to “0”
50 μs
DIMENSIONS AND WEIGHT
Dimensions (W x D x H)
39.9 x 137.0 x 141.5 mm;
(1.57 x 5.39 x 5.57 in)
Weight 0.285 kg
CABLES
One wire 14 AWG (2 mm
2
)
Two wires 20 AWG (0.5 mm
2
)
