SMAR LC700 - Procedure to Replace the Enet-700 for Enet-710

LC700 – User’s Guide
3.102
SERIAL PORTS P0-P4
Mode Asynchronus
Baud rate (bps) 9600, 19200, 38400, 57600 and 115200
Character size 8 bits
Parity Odd, even or none
Stop bits 1 or 2
Interface
RS-232C (P0, full-duplex, point to point)
RS-485 (P1 – 4, half-duplex, multidrop)
Protocols Modbus/RTU and CD600
Isolation
P0 – none
P1, P2 – 1600V
P3, P4 – 50V
INDICATOR LEDS
Power On (green)
Ethernet Link (green)
Serial
Activity in jack Tx/Rx (yellow)
Rx – yellow
Tx – green (for each port)
CONNECTORS
Ethernet 8 conductor modular RJ-45
Serial 3 conductor terminal blocks , 3.81 mm pitch
+24 Vdc Power Supply 3 conductor terminal block, 5.08 mm pitch
POWER SUPPLY
Internal 5 Vdc @ 450 mA typical
External
18-36Vdc, 130 mA typical @ 24Vdc
Recommended: 20-32 Vdc
DIMENSIONS AND WEIGHT
Dimensions (W x D x H)
39.9 x 137.0 x 141.5 mm
(1.57 x 5.39 x 5.57 in)
Weight 0.300 kg
Procedure to replace the ENET-700 for ENET-710
In the EIA-232 connection port, the connector DB-9 must be replaced by the 3 connector terminal (3
conductor terminal blocks – 3.81 mm). For the EIA-485 port, the 10 points connector must be
replaced by the 3 terminal connector (3 conductor terminal blocks – 3.81 mm), selecting one of the
ports P1 up to P4.
