SMAR LC700 - DC Discrete Output Module

LC700 – User’s Guide
3.74
M-102 – DC Discrete Output Module
(Supports Hot Swap and Device ID)
Part Number
M-102
(2 groups of 8 transistor Outputs (source))
Description
This Module is designed with NPN transistors that are able to drive relays, solenoids and other
loads with up to 1 A per output.
It has two groups of 8 optically isolated transistor outputs.
1
2
3
4
5
6
7
PWR-B
0
1
2
3
4
5
6
7
0
M-102
PWR-A
ID & Hot-Swap
smar
102/22 - 2 groups of 8 Transistors outputs - Source
PWR-B
PWR-A
GND-A
GND-B
1A
2A
3A
4A
5A
6A
7A
8A
9A
10A
1B
2B
3B
4B
5B
6B
7B
8B
9B
10B
Figure 3. 47- Transistor Outputs (Source) Module M-102
R
Green Led
IM
B
R
Red Led
R
1A
2A
3A
4A
5A
6A
7A
8A
9A
10A
1B
2B
3B
4B
5B
6B
7B
8B
9B
10B
PWR-B
PWR-A
GND-A
GND-B
Figure 3. 48 - External Connections
