SMAR LC700 - M-012;M-013 - Ac Discrete Input Module

LC700 – User’s Guide
3.56
M-012/M-013 - AC Discrete Input Module
(Supports Hot Swap and Device ID)
Part Number
M-012 (2 groups of 8 120 Vac digital inputs)
M-013 (2 groups of 8 240 Vac digital inputs)
Description
This Module senses the AC input Voltage and converts it to a True (ON) or False (OFF) logic signal.
It has 2 optically isolated groups of 8 inputs to detect 120/240 Vac (M-012/M-013 respectively).
1A
2A
3A
4A
5A
6A
7A
8A
9A
10A
1B
2B
3B
4B
5B
6B
7B
8B
9B
10B
012/18 - 2 Groups 8 120VAC Digital Inputs
+5VDC
0
1
2
3
4
5
6
7
0
1
2
3
4
5
6
7
smar
M-012
ID & Hot-Swap
smar
Figure 3.31 - AC Input Module M-012
AC NeutralA
In1A
In2A
AC NeutralB
R
Vcc
IM
B
Rin
R
V
cc
Green
Yellow
In3A
In1B
In2B
In3B
1A
2A
3A
4A
5A
6A
7A
8A
9A
10A
1B
2B
3B
4B
5B
6B
7B
8B
9B
10B
Figure 3.32 - External Connection
