SMAR LC700 - M-010;M-011 - Ac Discrete Input Module

LC700 – User’s Guide
3.54
M-010/M-011 - AC Discrete Input Module
Part Number
M-010 (2 groups of 4 120Vac digital inputs)
M-011 (2 groups of 4 240Vac digital inputs)
Description
This Module senses the AC input Voltage and converts it to a True (ON) or False (OFF) logic signal.
It has 2 optically isolated groups of 4 inputs to detect 120/240 Vac (M-010/M-011 respectively).
010/16 - 2 Groups 4 120VAC Digital Inputs
1A
2A
3A
4A
5A
6A
7A
9A
10A
1B
2B
3B
4B
5B
6B
7B
8B
9B
10B
8A
M-010
+5VDC
0
0
1
1
2
2
3
3
smar
smar
Figure 3.29– AC Input Module- M-010
AC NeutralA
In1
In2
In3
In4
AC NeutralB
In5
In6
In7
In8
R
Vcc
IMB
Rin
R
V
cc
Green
Y
ellow
1A
2A
3A
4A
5A
6A
7A
8A
9A
10A
1B
2B
3B
4B
5B
6B
7B
8B
9B
10B
Figure 3.30- External Connection
