SMAR LC700 - M-001;M-002;M-003;M-004 - DC Discrete Input Module

Modules And Accessories
3.49
M-001/M-002/M-003/M-004 - DC Discrete Input Module
(Supports Hot Swap and Device ID)
Part Number
M-001 (2 groups of 8 24 Vdc inputs isolated)
M-002 (2 groups of 8 48 Vdc inputs isolated)
M-003 (2 groups of 8 60 Vdc inputs isolated)
M-004 (2 groups of 8 125 Vdc inputs isolated)
Description
The Module senses the DC input Voltage and converts it into a True (ON) or False (OFF) logic
signal. It has 2 optically isolated groups of 8 inputs to detect 24/48/60/125 Vdc (M-001/M-002/M-
003/M-004 respectively).
001/11 - 2 Groups 8 24VDC Digital Inputs
PWR-A
10B
1A
PWR-B
GND-A
GND-B
2A
3A
4A
5A
6A
7A
8A
9A
10A
1B
2B
3B
4B
5B
6B
7B
8B
9B
1
2
3
4
5
6
7
PWR-B
0
1
2
3
4
5
6
7
smar
0
M-001
PWR-A
ID & Hot-Swap
smar
Figure 3.25 - DC Input Module M-001
R
R
V
cc
Yellow
Green
IM
B
In1A
In2A
In1B
V
ext1
V
ext2
In2B
1A
2A
3A
4A
5A
6A
7A
8A
9A
10A
1B
2B
3B
4B
5B
6B
7B
8B
9B
10B
PWR-A
PWR-B
GND-A
GND-B
Figure 3.26 – External Connection
