SMAR LC700 - Installing the Systems Base with R-700-4 A Rack

LC700 Architecture
2.13
Installing the system’s base with R-700-4A rack
See below the figures and descriptions of module and rack:
Figure 2.23 - ENET-710 Module
A. Joining the
Rack
K. Digital Ground
J. Flat Cable
I. Flat Cable
Connector
(Bottom)
H. Clips
G. Rack Address
Switch
F. Module
Connector
E. Flat Cable
Connector (Top)
D. DIN
C. Module
support
B. Jumper
W1
Slot 0
Slot 1
Slot 2
Slot 3
Rail
L. Connection
of the Rail
Figure 2.24 - Rack – R-700-4
