LC700 – User’s Guide
3.108
FIXATION
Through a support for DIN rail or using empty slots of a rack model R-700-4 (rack with four slots)
(installation).
DIMENSIONS AND WEIGHT
Dimensions (W x D x H) 40 x 127 x 142 mm; (1.57 x 5.00 x 5.59 in)
Weight 0.265 kg
232 Interface
OPERATION MODE Full Duplex or Half Duplex
PROTECTION Voltage peaks
CABLING
Up to 15 m (25 m with shielding), between ICS2.0P and the
232 device
CONNECTION
Pin I/O Signal Description
2 O TxD Output 232 signal to be sent to the receiver of the 232 device
3 I RxD Input 232 signal to be sent to the transmitter of the 232 device
5 - GND Reference grounding of the 232 signals.
Connection: 3 wires, TxD, RxD and GnD and through the 9 pins Delta connector, female.
485 Interface
OPERATION MODE
Automatic control of the transmission driver, independent of
the baud rate.
TERMINATORS
Activation through jumpers
PROTECTION
Voltage Peaks
CABLING
Up to 1200 m, without repeater, using two twisted pairs and
with shielding.
Obs.: Connect the shielding to the grounding
pin GND
.
CONNECTION
Pin I/O Signal Description
1 I/O +
485 positive differential signal
2 I/O -
485 negative differential signal
3 - GND
Grounding. Usefull to eliminate the effects of common mode voltage.
Connection: 3 wires. With differential signals (+) and (-) and grounding GND.
