Modules And Accessories
3.73
Warning
This module has an internal protection against inductive load switching. Each digital output
terminal has a diode that supresses the reverse voltage peak created by inductive loads. To make
it, it is necessary to connect the power supply of the loads in the terminal 1A, so that these dyodes
are placed in parallel with the load. If we do not make this connection and if we do not have
necessary power supply to the modules, the diode conducts and activates the loads.
Technical Specifications
ARCHITECTURE
Number of inputs 16
Number of groups 1
Number of points per group 16
ISOLATION
Optical Isolation up to 5000 Vac
EXTERNAL SOURCE
Voltage source for outputs 20 to 30 Vdc
Maximum consumption 65 mA
Power Supply Indicator Green LED
INTERNAL SOURCE
Provided by the IMB bus 5 Vdc @ 70 mA maximum
Total Maximum Dissipation 0.35 W
Power Supply Indicator None
OUTPUTS
Maximum Switched Voltage 30 Vdc
Maximum Saturation Voltage 0.55 V @ 0.5 A
Maximum Current per Output 0.5 A
Status Display Yellow LED
Indicator Logic LED ON- when the transistor is ON
Maximum Leakage Current 10 μA @ 35 Vdc
Switch Capacity for Bulbs 15 W
INDEPENDENT PROTECTION PER OUTPUT
Thermal Shutdown 165 ºC
Thermal Hysteresis 15 ºC
Overcurrent protection 1.3 A @ 25 Vdc maximum
SWITCHING INFORMATION
Time from 0 a 1 250 μs
Time from 1 a 0 3 μs
DIMENSIONS AND WEIGHT
Dimensions (W x D x H)
39.9 x 137.0 x 141.5 mm;
(1.57 x 5.39 x 5.57 in)
Weight 0.260 kg
CABLES
One Wire 14 AWG (2 mm
2
)
Two Wires 20 AWG (0.5 mm
2
)
