Modules And Accessories
3.129
T-700 - IMB terminator for right side
Part Number
T-700 (IMB Terminator for the Last Rack)
Description
The Rack Terminator must be always used in the last rack in order to do the correct impedance
matching of the IMB signals.
Figure 3.87 – T-700 (Rack Terminator)
NOTE
For further details about its installation refer to T-700, Chapter 2.
DF96 – IMB terminator for left side
Part Number
DF96 (IMB terminator for left side)
Description
It is connected to connector E of the last rack, when it is connected to the others by the right side.
See the next figure.
Figure 3.88 - DF96 terminator
NOTE
For further details about its installation refer to DF96, Chapter 2.
