Technical Specifications
ARCHITECTURE
Number Of Outputs 8
Number of groups 2
Number of points per group 4
ISOLATION
Groups are isolated individually
Optical isolation up to 2500 Vac
EXTERNAL SOURCE
Voltage Source 20 to 240 Vac, 45 to 65 Hz
Maximum Consumption per group 4 A
Power Supply Indicator None
Protection One fuse per group
INTERNAL SOURCE
Provided by the IMB bus 5 Vdc @ 70 mA maximum
Total Maximum Dissipation 0.35 W
Power Supply Indicator Green LED
OUTPUTS
Voltage Output 20 to 240 Vac, 45-65 Hz
Maximum Current per Output 1 A
Maximum Total Current per Group
4 A @ Tamb 0-40 ºC (32-104 ºF)
2 A @ Tamb 40-60 ºC (104-140 ºF)
Maximum Surge Current 15 A / 0.5 cycle, 1 surge per minute maximum
Status Display Yellow LED
Indicator Logic When Active
Off state Voltage Leakage Current
500
μA @ 100 Vac
On state Voltage drop 1.5 Vac rms maximum
Over Load Protection per Output
Should be provided externally (fast acting fuse
rated at 1.5 times user continuous current).
SWITCHING INFORMATION
Zero cross operation; Ton, Toff 1/2 cycle
RC circuit for protection 62 Ω in series with 0.01 μF
DIMENSIONS AND WEIGHT
Dimensions (W x D x H)
39.9 x 137.0 x 141.5 mm;
(1.57 x 5.39 x 5.57 in)
Weight 0.295 kg
CABLES
One Wire 14 AWG (2 mm
2
)
Two Wires 20 AWG (0.5 mm
2
)
