Technical Specifications
ARCHITECTURE
Number of inputs 8
Number of groups 2
Number of points per group 4
ISOLATION
Groups are isolated individually
Optical Isolation up tp 5000 Vac
EXTERNAL SOURCE
Voltage Source for inputs
120 Vac (M-010)
240 Vac (M-011)
Typical consumption per point 10 mA
Power Supply Indicator None
INTERNAL SOURCE
Supplied by the IMB bus 5 Vdc @ 50 mA maximum
Maximum Total Dissipation 0.25 W
Power Supply Indicator Green LED
INPUTS
ON State Voltage Range (logic “1”)
100-140 Vac (M-010)
200-264 Vac (M-011)
OFF State Voltage Range (logic “0”)
0-30 Vac (M-010)
0-50 Vac (M-011)
Input Current (Typical) 10 mA @ 60 Hz
Power Supply Indicator Yellow LED
SWITCHING INFORMATION
Minimum Voltage for logic level “0”
100 Vac (M-010), 45 to 60 Hz
200 Vac (M-011), 45 to 60 Hz
Maximum Voltage for logic level “0”
30 Vac (M-010), 45 to 60 Hz
50 Vac (M-011), 45 to 60 Hz
Typical Hysteresis
70 Vac (M-010)
150 Vac (M-011)
Time from 0 to 1 5 ms
Time from 1 to 0 42 ms
DIMENSIONS AND WEIGHT
Dimensions (W x D x H)
39.9 x 137.0 x 141.5 mm;
(1.57 x 5.39 x 5.57 in)
Weight 0.285 kg
CABLES
One Wire 14 AWG (2 mm
2
)
Two Wires 20 AWG (0.5 mm
2
)
