Technical Specifications
CPU
Type
Low Power Microcontroller
Architecture
8-bit CISC
MEMORY
Capacity Functionality
Code
512 kB, 8-bit Flash Downloadable firmware
Data
128 kB, 8-bit RAM Dynamic data
Retention
8 kB, 8-bit serial EEPROM Configuration retention
Dual-Port
32 kB, 8-bit DPRAM LC700 interface
FIELDBUS INTERFACE
Number of Channels 1 H1 channel (31,25 Kbps)
Controller FB3050 SMAR (DMA Integrated)
Physical Layer Standard
ISA-S50.02-1992
Fieldbus Interface
Passive (not bus powered)
Intrinsic Safety
NOT compliant
INTERNAL SOURCE
Supplied by the IMB bus 5 Vdc @ 110 mA
Total Maximum Dissipation 0.55 W
Source Indicator Green LED + 5 Vdc
TEMPERATURE
Operation 0 to 60 ºC
Storage -20 to 80 ºC
ISOLATION
IMB Communication Channel 500 Vac
DIMENSIONS AND WEIGHT
Dimensions (W x H x D)
39.9 x 137.0 x 141.5 mm
(1.57 x 5.39 x 5.57 in)
Weight 0.261 kg
CABLES
One Wire 14 AWG (2 mm
2
)
Two Wires 20 AWG (0.5 mm
2
)
