SMAR LC700 - Technical Specifications

Modules And Accessories
3.75
Technical Specifications
ARCHITECTURE
Number of inputs 16
Number of groups 2
Number of points per group 8
ISOLATION
Optical isolation up to 5000 Vac
EXTERNAL SOURCE
Voltage source per output 20 to 35 Vdc
Maximum consumption 65 mA
Power Supply Indicator Green LED
INTERNAL SOURCE
Provided by the IMB bus 5 Vdc @ 70 mA maximum
Total Maximum Dissipation 0.35 W
Power Supply Indicator None
OUTPUTS
Maximum Switched Voltage 35 Vdc
Maximum Saturation Voltage 0.3 V@ 1 A
Maximum Current per Output 1 A
Status Display Yellow LED
Indicator Logic LED ON- Transistor in ON
Maximum Leakage Current 200 μA @ 35 Vdc
Switch Capacity for Bulbs 15 W
INDEPENDENT PROTECTION PER OUTPUT
Overload Protection 5.3 A
SWITCHING INFORMATION
Time from 0 to 1 600 μs
Time from 1 to 0 300 μs
DIMENSIONS AND WEIGHT
Dimensions (W x D x H)
39.9 x 137.0 x 141.5 mm;
(1.57 x 5.39 x 5.57 in)
Weight 0.260 kg
CABLES
One Wire 14 AWG (2 mm
2
)
Two Wires 20 AWG (0.5 mm
2
)
