LC700 – User’s Guide
3.92
FB-700 - FIELDBUS MODULE
(Supports Hot Swap and Device ID)
Part Number
FB-700 (Fieldbus Module)
Description
The FB-700 is a Fieldbus interface card for the LC700 programmable controller. It integrates the
discrete control capability of LC700 with Fieldbus.
The Foundation™ Fieldbus interoperability feature assures that the FB-700 will work perfectly with
any other FF device, even from manufacturers other than Smar.
The FB-700 is directly attached to the LC700 backplane. The LC700 accesses it as a regular I/O
card, which supports many digital and analog I/O points mapped to the FB-700 function blocks. For
proper operation, both CONF700 and SYSCON should configure the card.
Function Blocks
FB-700 can execute the following function blocks, some of which are pre-instantiated:
Block Type Description
Number of
instantiations
RS Resource 1
DIAG Diagnostics Transducer 1
MAI Multiple Analogic Inputs 2
MDI Multiple Discrete Inputs 3
PID PID Control 1
EPID Enhanced PID Control 0
ARTH Arithmetic 0
SPLT Split Range 0
CHAR Signal Characterizer 0
INTG Integrator 0
AALM Analogic Alarm 1
ISEL Input Selector 0
SPG Set point Ramp Generator 0
TIME Time and Logic 0
LLAG Lead-Lag 0
OSDL
Output Selector/Dynamic
Limiter
0
CT Constant 0
MAO Multiple Analogic Output 2
MDO Multiple Discrete Output 4
In the table above:
- Block Type: it means the available block types for the device
- Description: it shows the description of each block.
- Number of instantiations:
0 – this block type is not pre-instantiated in the FB-700.
1 to 4 – it indicates the quantity of pre-instantiated blocks in the FB-700.
There are blocks that have correlation with the LC700. These blocks are described below:
