OUTPUTS
M-122
1 group of 4 N.O. and 1 Group of 4 N.C. Relay Outputs (optically isolated)
M-123
2 groups of 8 N.O. Relays Outputs (optically isolated)
M-124
2 groups of 4 N.O. Relay Outputs (optically isolated)
M-125
2 groups of 4 N.C. Relay Outputs (optically isolated)
M-126
1 group of 4 N.O. and 1 Group of 4 N.C. Relay Outputs (optically isolated)
M-127 2 groups of 8 N.O Relay Outputs with internal RC (optically isolated)
M-501 4 Current and Voltage Analog Outputs (optically isolated)
INPUTS/OUTPUTS
M-201 1 group of 8 24 Vdc Inputs and 1 Group of 4 N.O. Relay Outputs (optically isolated)
M-202 1 group of 8 48 Vdc Inputs and 1 Group of 4 N.O. Relay Outputs (optically isolated)
M-203 1 group of 8 60 Vdc Inputs and 1 Group of 4 N.O. Relay Outputs (optically isolated)
M-204 1 group of 8 24 Vdc Inputs and 1 Group of 4 N.C. Relay Outputs (optically isolated)
M-205 1 group of 8 48 Vdc Inputs and 1 Group of 4 N.C. Relay Outputs (optically isolated)
M-206 1 group of 8 60 Vdc Inputs and 1 Group of 4 N.C. Relay Outputs (optically isolated)
M-207 1 group of 8 24 Vdc Inputs and 1 Group with 2 N.O. and 2 N.C. Relay Outputs (optically isolated)
M-208 1 group of 8 48 Vdc Inputs and 1 Group with 2 N.O. and 2 N.C. Relay Outputs (optically isolated)
M-209 1 group of 8 60 Vdc Inputs and 1 Group with 2 N.O. and 2 N.C. Relay Outputs (optically isolated)
OTHER MODULES
RIO-700-D3
Remote I/O Interface Module
RIO-700-E3
Remote I/O Interface Module
FB-700
One H1 Fieldbus Foundation Channel Module (Isolated)
ENET-700 Modbus/TCP 10Base-T Ethernet Module
ENET-710 MODBUS / CDBUS TCP 10/100 Base-T Ethernet Module
MB-700 Modbus RTU and TCP/IP Processor Module
SI-700 EIA-232/ EIA RS485 Interface Module
OPT-700 EIA-232/ EIA RS485 Interface Module
SW-700 Ethernet Switch Module
ICS2.0P Serial Converter Interface
SOFTWARE
CONF700 LC700 Configurator, Programming Tool and Optimizer
SYSCON Fieldbus network configurator
CABLES AND ACCESSORIES
R-700-4A Rack with 4 slots - support to shielded flat cable
DF93 Rack with 4 slots, with diagnostic
C232-700 EIA-232 Cable to connect LC700/FB-700 and computer (183 cm)
C232-1-700 EIA232 Cable to connect CPU-700-X3 and ENET-700 (X means D or E)
C232-2-700 EIA -232 Cable to connect CPU-700-X3R and ENET-700 (X means D or E)
C232-3-700 EIA-232 Cable to connect CPU-700-X3 and MB-700 (X means D or E)
C232-4-700 EIA-232 Cable to connect CPU-700-X3R and MB-700 (X means D or E)
ICP-700 Cable to connect coprocessors - CPU-700-C3R
ICP-700-D3 Cable to connect coprocessors – CPU-700-E3R/D3R
DF90 IMB power cable
DB9-EXT Extension for DB9 connector
FC-700-0 Flat Cable to connect 2 racks (6.5 cm)
FC-700-1 Flat cable to connect 2 racks (65.0 cm)
FC-700-2 Flat cable to connect 2 racks (81.5 cm)
FC-700-3 Flat cable to connect 2 racks (98.0 cm)
FC-700-4 Flat cable to connect 2 racks (114.0 cm)
FC-700-1A Shielded Flat cable to connect 2 racks (65.0 cm)
FC-700-2A Shielded Flat cable to connect 2 racks (81.5 cm)
FC-700-3A Shielded Flat cable to connect 2 racks (98.0 cm)
