SMAR LC700 - Page 107

Modules And Accessories
3.69
DIMENSIONS AND WEIGHT
Dimensions (W x D x H)
39.9 x 137.0 x 141.5 mm;
(1.57 x 5.39 x 5.57 in)
Weight 0.202 kg
CABLES
One wire 14 AWG (2 mm
2
)
Two wires 20 AWG (0.5 mm
2
)
2 OR 3 WIRES DIFFERENTIAL
SENSOR
TYPE RANGE [ºC] RANGE [ºF] RANGE [ºC] RANGE [ºF]
Cu10 GE -20 to 250 -4 to 482 -270 to 270 -486 to 486
Ni 120 DIN -50 to 270 -58 to 518 -320 to 320 -576 to 576
Pt50 IEC -200 to 850 -328 to 1562 -1050 to 1050 -1890 to 1890
Pt100 IEC -200 to 850 -328 to 1562 -1050 to 1050 -1890 to 1890
Pt500 IEC -200 to 450 -328 to 842 -650 to 650 -1170 to 1170
Pt50 JIS -200 to 600 -328 to 1112 -800 to 800 -1440 to 1440
RTD
Pt100 JIS -200 to 600 -328 to 1112 -800 to 800 -1440 to 1440
B NBS +100 to 1800 +212 to 3272 -1700 to 1700 -3060 to 3060
E NBS -100 to 1000 -148 to 1832 -1100 to 1100 -1980 to 1980
J NBS -150 to 750 -238 to 1382 -900 to 900 -1620 to 1620
K NBS -200 to 1350 -328 to 2462 -1550 to 1550 -2790 to 2790
N NBS -100 to 1300 -148 to 2372 -1400 to 1400 -2520 to 2520
R NBS 0 to 1750 32 to 3182 -1750 to 1750 -3150 to 3150
S NBS 0 to 1750 32 to 3182 -1750 to 1750 -3150 to 3150
T NBS -200 to 400 -328 to 752 -600 to 600 -1080 to 1080
L DIN -200 to 900 -328 to 1652 -1100 to 1100 -1980 to 1980
THERMO-
COUPLE
U DIN -200 to 600 -328 to 1112 -800 to 800 -1440 to 1440
2 WIRES DIFFERENTIAL RANGE
-6 a 22 mV -28 a 28 mV
1
-10 a 100 mV -110 a 110 mV
2
SENSOR
MV
-50 a 500 mV -550 a 550 mV
3
2 OR 3 WIRES DIFFERENTIAL RANGE
0 a 100 Ω -100 a 100 Ω
4
0 a 400 Ω -400 a 400 Ω
5
SENSOR
Ω
0 a 2000 Ω -2000 a 2000 Ω
6
