LC700 – User’s Guide
3.122
C232-4-700 - EIA -232 Cable to connect CPU-700-X3R* and MB-700
Part Number
C232-4-700 (Cable to connect CPU-700R and MB-700)
CABLE CONNECTION DIAGRAM
DB(MALE)
CPU
DB(MALE)
CPU
CABLE ASSEMBLY
PIN 1
PIN 1
LABEL ID
THERMINAL 1
ADHESIVE
PROTECTION
FIAT CABLE 26 AWG 4 VIAS
SHIELDED CABLE 26 AWG 2 PAIRS
FR
O
NT
THERMINAL 1
PIN 1
Figure 3.79 - EIA-232 Cable for CPU-700- X3R and MB-700
* X means D or E.
