LC700- Manual de instalação
4.3
The uses of the procedures on Table 4.2 are illustrated on Figure 4.1.
CATEGORY 1
CATEGORY 1CATEGORY 2CATEGORY 2
RACEWAY FOR EXTERNAL CABLES
RACEWAY FOR EXTERNAL CABLES
RACEWAY FOR INTERNAL CABLES
RACEWAY FOR INTERNAL CABLES
RACEWAY FOR INTERNAL CABLES
RACEWAY FOR EXTERNAL CABLES
RACEWAY FO R EXTERNAL CABLES
RACEWAY FOR INTERNAL CABLES
CIRCUIT
BREAKER
Figure 4.1 – Assembling Details
