Modules And Accessories
3.51
SWITCHING INFORMATION
Maximum Voltage for logic level “0”
5 Vdc (M-001)
9 Vdc (M-002)
12 Vdc (M-003)
25 Vdc (M-004)
Time from “0” to “1”
30 μs
Time from “1” to “0”
50 μs
DIMENSIONS AND WEIGHT
Dimensions (W x D x H)
39.9 x 137.0 x 141.5 mm;
(1.57 x 5.39 x 5.57 in)
Weight 0.285 kg
CABLES
One Wire 14 AWG (2 mm
2
)
Two Wires 20 AWG (0.5 mm
2
)
