Smartrise C4 User Manual

C4 User Manual
Page 342 ©2021 Smartrise Engineering, Inc. All Rights Reserved October 25, 2021
Data Index
Name
Description
11
CT CAN 4
CT board CAN4, CEDES camera channel 1.
12
CT A NET
CT board A processor RS232 Network.
Shows errors in packets received by the A processor, sent by the B
processor.
13
CT B NET
CT board B processor RS232 Network.
Shows errors in packets received by the B processor, sent by the A
processor.
14
CT RS485
CT board RS485 network.
15
COP CAN 1
COP board CAN1, Car Network (CN1+/-).
16
COP CAN 2
COP board CAN2, CEDES camera #2 channel 2.
17
COP CAN 3
COP board CAN3, Aux Network (C3H/L).
18
COP CAN 4
COP board CAN4, CEDES camera #2 channel 1.
19
COP A NET
COP board A processor RS232 Network.
Shows errors in packets received by the A processor, sent by the B
processor.
20
COP B NET
COP board B processor RS232 Network.
Shows errors in packets received by the B processor, sent by the A
processor.
21
COP RS485
COP board RS485 Network.
22
Run Signal
Displays car run signals as a string of binary digits. From right to left,
functions are mapped to this list, from top to bottom:
• Destination Chosen, Run Requested
• Car Doors Closed
• Hall Locks Closed
• Motion Run Flag ON
• DSD Drive HW Enable
• Pick M Contactor
• M Contactor Feedback
• Drive Energize Commanded
• Pick B Contactor
• Serial Speed Reg Rls
• Brake Pick Command
• BPS (Software)
• E-Brake Pick Command
• E-BPS (Software)
• Command Speed Nonzero
• Camera Speed Nonzero
23
Last Stop
Pos
Displays the position the car stopped at last run. Only records for
normal run stops at the start of the brake drop stop sequence state.
24
MRA Vers.
Displays the third segment of the processor A software version number
on the MR board up to 4 characters.
