C4 User Manual
October 25, 2021 ©2021 Smartrise Engineering, Inc. All Rights Reserved Page 39
Assign inputs to the Expansion 17-24 boards
Assign inputs to the Expansion 25-32 boards
Assign inputs to the Expansion 33-40 boards
Assign outputs from the MR board
Assign outputs from the CT board
Assign outputs from the COP board
Assign outputs from the Riser board
Assign outputs from the Expansion 1-8 boards
Assign outputs from the Expansion 9-16 boards
Assign outputs from the Expansion 17-24 boards
Assign outputs from the Expansion 25-32 boards
Assign outputs from the Expansion 33-40 boards
Adjust speed deviation options
Adjust traction loss options
The amount of time the controller disregards an open hall
lock. This prevents intermittent interlock faults and for
safety reasons, this timer should not exceed five seconds
Inspection overspeed debounce limit
Door open overspeed debounce limit
ETS overspeed debounce limit
Relay feedback debounce limit
General overspeed debounce limit
NTS overspeed debounce limit
Construction overspeed debounce limit
Sets the emergency brake on overspeed faults
Disables construction overspeed setting
Shifts learned ETS position by user defined offset from
NTS points
Option for reduced stroke buffer
The speed which speed deviation detection is activated
How long speed deviation is detected before triggering
fault
Percent change between feedback and command speed
for triggering the speed deviation fault
The speed which traction loss detection is activated
Amount of time for traction loss to be present before a
fault is issued
