C4 User Manual
Page 40 ©2021 Smartrise Engineering, Inc. All Rights Reserved October 25, 2021
Percent offset between drive and position system speed
feedback
Timers used for motion start sequence
Timers used for motion stop sequence
Enable/Disables ETSL operation
ETSL overspeed debounce limit. Sets of sensitivity of the
ETSL device. This setting is only increased to avoid
nuisance tripping.
Rated speed of the buffer installed
Distance from the bottom of the cab to the buffer
Distance determined by the ETSL slide distance test
Camera offset between main camera and ETSL camera.
This is automatically calculated during learn operation.
Sets a delay before moving into acceleration stage of
pattern on automatic operation. This holds the car at zero
speed (or at min accel speed if set).
Sets a delay before moving into acceleration stage of
pattern on inspection operation. This holds the car at zero
speed (or at min accel speed if set).
Delays the lifting of the main brake on automatic
operation
Delays the lifting of the main brake on inspection
operation
Sets delay between reaching zero speed and dropping the
primary brake on automatic operation
Sets delay between reaching zero speed and dropping the
primary brake on inspection operation
Sets delay between checking BPS and dropping drive
control on automatic operation
Sets delay between checking BPS and dropping drive
control on inspection operation
Sets delay between dropping drive control and dropping
the M contactor on automatic operation
Sets delay between dropping drive control and dropping
the M contactor on inspection operation
Sets delay between dropping the secondary brake and
dropping the B2 contactor while in automatic operation
Sets delay between dropping the secondary brake and
dropping the B2 contactor on inspection operation
