C4 User Manual
October 25, 2021 ©2021 Smartrise Engineering, Inc. All Rights Reserved Page 55
Sets the main recall opening as front or rear
Sets whether the elevator will recall to the main or
alternate landing when the main smoke is active
Flash fire hat when main smoke is active
Activates fire shunt output during Phase 1 recall if
triggered by main smoke input
Sets whether the elevator will recall to the main or
alternate landing when the alternate smoke is active
Flash fire hat when alternate smoke is active
Activates fire shunt output during Phase 1 recall if
triggered by alternate smoke input
Sets whether the elevator will recall to the main or
alternate landing when the hoistway smoke is active
Flash fire hat when hoistway smoke is active
Activates fire shunt output during Phase 1 recall if
triggered by hoistway smoke input
Sets whether the elevator will recall to the main or
alternate landing when the machine room smoke is
active
Flash fire hat when machine room smoke is active
Activates fire shunt output during Phase 1 recall if
triggered by machine room smoke input
Flash fire hat when recall key is turned to the ON
position
Sets whether the elevator recalls to the main or
alternate landing when the pit smoke is active
Flash fire hat when pit smoke is active
Activates fire shunt output during Phase 1 recall if
triggered by pit smoke input
Enables alternate machine room fire operation setup
menu
Alternate hoistway smoke options
Alternate machine room smoke options
