Smartrise C4 User Manual

C4 User Manual
Page 56 ©2021 Smartrise Engineering, Inc. All Rights Reserved October 25, 2021
Menu
Description
HW 2 Smoke
Main or Alt
Sets whether the elevator recalls to the main or
alternate landing when alternate machine room smoke
is active
Flash Fire Hat
Flash fire hat when alternate machine room smoke is
active
Shunt Trip
Activates fire shunt output during Phase 1 recall if
triggered by alternate machine room smoke input
MR 2 Smoke
Main or Alt
Sets whether the elevator recalls to the main or
alternate landing when the alternate machine room
smoke is active
Flash Fire Hat
Flash fire hat when alternate machine room smoke is
active
Shunt Trip
Activates fire shunt output during Phase 1 recall if
triggered by alternate machine room smoke input
Earthquake
Enable EQ
Enables earthquake options
Set CW POS
Set the CW midpoint position
