C
LASS
OF
S
ERVICE
C
ONFIGURATION
2-135
Web – Click Priority, Traffic Classes. Mark an interface and click Select to
display the current mapping of CoS values to output queues. Assign
priorities to the traffic classes (i.e., output queues) for the selected
interface, then click Apply.
CLI – The following example shows how to map CoS values 1 and 2 to
CoS egress queue 0, value 0 and 3 to CoS egress queue 1, values 4 and 5 to
CoS egress queue 2, and values 6 and 7 to CoS egress queue 3.
Console(config)#interface ethernet 1/1
Console(config)#queue cos-map 0 1 2 3-192
Console(config)#queue cos-map 1 0 3
Console(config)#queue cos-map 2 4 5
Console(config)#queue cos-map 3 6 7
Console(config)#exit
Console#show queue cos-map ethernet 1/1 3-195
Information of Eth 1/1
Queue ID Traffic class
-------- -------------
0 1 2
1 0 3
2 4 5
3 6 7
Console#
