M AIN M ENU
2-7
Address Table 2-86
Static Addresses Displays entries for interface, address or VLAN 2-86
Dynamic Addresses Displays or edits static entries in the Address Table 2-87
Address Aging Sets timeout for dynamically learned entries 2-89
Spanning Tree 2-90
STA Information Displays STA values used for the bridge 2-91
STA Configuration Configures global bridge settings for STA 2-91
STA Port
Information
Displays individual port settings for STA 2-98
STA Trunk
Information
Displays individual trunk settings for STA 2-98
STA Port
Configuration
Configures individual port settings for STA 2-102
STA Trunk
Configuration
Configures individual trunk settings for STA 2-102
VLAN 2-106
VLAN Basic
Information
Displays basic information on the VLAN type
supported by this switch
2-110
VLAN Current
Table
Shows the current port members of each VLAN
and whether or not the port is tagged or untagged
2-111
VLAN Static List Used to create or remove VLAN groups 2-113
VLAN Static Table Modifies the settings for an existing VLAN 2-115
VLAN Static
Membership
Configures membership type for interfaces,
including tagged, untagged or forbidden
2-117
VLAN Port
Configuration
Specifies default PVID and VLAN attributes 2-118
VLAN Trunk
Configuration
Specifies default trunk VID and VLAN attributes 2-118
Private VLAN
Information
Displays Private VLAN feature information 2-123
Private VLAN
Configuration
This page is used to create/remove primary or
community VLANs
2-124
Private VLAN
Association
Each community VLAN must be associated with a
primary VLAN
2-126
Menu Description Page
