SMC Networks 6724AL2 User Manual

C ONFIGURING THE S WITCH
2-8
Private VLAN Port/
Trunk Information
Displays the interfaces associated with private
VLANs
2-127
Private VLAN Port/
Trunk Configuration
Sets the private VLAN interface type, and
associates the interfaces with a private VLAN
2-128
Priority 2-131
Port Priority
Configuration
Sets the default priority for each port 2-131
Trunk Priority
Configuration
Sets the default priority for each trunk 2-131
Traffic Classes Maps IEEE 802.1p priority tags to output queues 2-133
Queue Mode Sets queue mode to strict priority or Weighted
Round-Robin
2-136
Queue Scheduling Configures Weighted Round Robin queueing 2-137
IP Precedence/
DSCP Priority Status
Globally selects IP Precedence or DSCP Priority, or
disables both
2-138
IP Precedence
Priority
Sets IP Type of Service priority, mapping the
precedence tag to a class-of-service value
2-140
IP DSCP Priority Sets IP Differentiated Services Code Point priority,
mapping a DSCP tag to a class-of-service value
2-142
IP Port Priority
Status
Globally enables or disables IP Port Priority 2-144
IP Port Priority Sets TCP/UDP port priority, defining the socket
number and associated class-of-service value
2-144
ACL CoS Mapping Sets the CoS value and corresponding output queue
for packets matching an ACL rule
2-146
IGMP Snooping
IGMP
Configuration
Enables multicast filtering; configures parameters
for multicast query
2-148
Multicast Router
Port Information
Displays the ports that are attached to a
neighboring multicast router/switch for each
VLAN ID
2-151
Static Multicast
Router Port
Configuration
Assigns ports that are attached to a neighboring
multicast router/switch
2-152
