Sonoscape S20 Plus User Manual

2 System Overview
12 Basic User Manual
No. Name Description
<6> Scale Knob Rotate it to adjust the image when activating the zoom feature.
<7> Zoom Press it to activate the zoom feature.
<8> 3D/4D Press it to enter or exit the 3D/4D mode.
<9> Dual Press it to enter the dual split display.
Or, press it to activate the desired image in the dual split display.
<10> Report
Press it to enter the
Report
screen.
<11> P1 Press it to save images, cine or volume data. For details, refer to Section 4.1.4
Dened-Key Settings.
<12> Print Press it to trigger the network printer if the network printer is successfully connected.
<13> Video Print Press it to print the current screenshot if the video printer is successfully connected.
<14> Save Press it to save cine in the frozen mode.
<15> Clear Press it to remove all measurement results, annotations and body mark symbols from
the display.
<16> M Press it to enter the inactivated M mode.
Or, rotate it to adjust the gain value in the M mode.
<17> CW Press it to enter the inactivated CW mode.
Or, rotate it to adjust the gain value in the CW mode.
<18> PW Press it to enter the inactivated PW mode.
Or, rotate it to adjust the gain value in the PW mode.
<19> CFM Press it to enter the CFM mode.
Or, rotate it to adjust the gain value in the CFM mode.
In 3D/4D mode, rotate it to move the 3D image horizontally.
<20> B Press it to enter the B mode.
Or, rotate it to adjust the gain value in the B mode.
<21> Conrm Key Dened as the conrm key.
Press it to conrm the current operation.
<22> Pointer Press it to activate the clipboard in the 2D (B/CFM/PDI/TDI)/M mode.
Or, press it to activate the cursor in the 3D/4D mode.
<23> Annot Press it to annotate an image with typed words.
<24> Update
●
Press it to enter the M/PW/CW mode in inactivated M/PW/CW mode.
●
Press it to switch between measurement markers when performing the distance
or ellipse measurement.
●
Press it to undo the trace when performing a trace measurement.
<25> Calc Press to activate the application-specic measurement and calculation features.
