4 Customizing Your System
36 Basic User Manual
Item Description
Ellip. Cross Line Disp. Enable or disable the display of dash lines for long and short axes when performing
a ellipse measurement.
Line ID Disp. Enable or disable the display of line number when performing a measurement.
Keep Result Window Enable or disable the display of the current result box when unfreezing the image.
Freeze on Measure
Enable or disable the frozen feature after pressing the
Calc
or
Caliper
key in the
real-time mode.
Result Font Size Set the font size of the result box.
■ Result Position
Item Description
2D Set the position of the result box.
Choose from: Right Top, Right Bottom, Left Top or Left Bottom
Dual+Quad
M
Doppler
4.5.2 Application Settings
Measurement Setting
AC/BPD(Hadlock)
Hadlock
Williams
kg
BPD,HC,AC,FL
Equation
GA&Growth
No
Add 1 week to EDD
Estimation
Age by EFW
EFW GP/SD
Unit
No
New Table
Show EDD on screen
AUA
CUA/AUA
Auto/Man Trace
Fetal Weight
CUA
CUA
Load Default
General
Application List
Application
PS
OB
ED
RI
PI
S/D
TAmax
TAmean
VTI
HR
Num 1
...
Num 2
...
Num 3
...
Num 4
...
Num 5
...
Num 6
...
Num 7
...
Num 8
...
Num 9
...
Num 0
...
Shortcut Key
System Setting
Peripheral
General
Comment
Measure
Bodymark
Report
DICOM
Load Default
User Security
About
Exit
Save&Exit
No
Growth Dev. Display
Figure 4-10 Measurement Settings Menu - Formula Tab
■ Auto/Man Trace
After selecting an exam type from the application drop-down list, set the measurement items of Auto/manual trace
in the spectral Doppler mode.
