2 System Overview
Basic User Manual 13
No. Name Description
<26> Caliper
Press to activate the basic measurement and calculation features.
●
Press it to perform the distance measurement in the 2D (B/CFM/PDI/TDI)/
M/3D/4D mode.
●
Or, press it to activate the velocity measurement in the PW/CW mode.
<27> Trackball Use it to move the cursor and adjust ROI.
<28> -Audio+ Rotate it to adjust the volume.
<29> TGC Use these sliders to adjust the TGC settings at different scan depth.
<30> m-tunning Press it to optimize an image automatically.
<31> Angle
●
Rotate it to adjust the ow direction in the PW/CW mode.
●
Rotate it to adjust the angle of M line in the M mode.
●
Rotate it to adjust the arrow direction if the arrow annotation feature is activated.
●
Rotate it to adjust the probe direction if the body mark feature is activated.
●
Rotate it to adjust the angle of hip joint when performing the pediatrics
measurement.
<32> Arrow Press it to add arrows on an image.
<33> Body Mark Press it to add body marks on an image.
<34> Depth Rotate it to adjust the scan depth.
<35> Save
●
In the real-time mode or frozen mode, press it to save an image.
●
In the real-time contrast imaging mode, press it to set the start frame for a cine of
blood ow, and press it again to set the end frame.
<36> Freeze Press it to freeze an image in the real time mode.
Or, press it again to restore the real time scan.
