5-22
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
! C977 1-113-521-11 CERAMIC CHIP 12PF 10% 3KV
C978 1-164-360-11 CERAMIC CHIP 0.1uF 16V
< CONNECTOR >
CN802 1-770-629-21 PIN, CONNECTOR 12P
CN803 1-691-386-11 CONNECTOR, FFC/FPC 22P
CN804 1-764-708-21 CONNECTOR, FFC/FPC (LIF) 9P
CN807 1-766-346-21 CONNECTOR, FFC/FPC 16P
CN951 1-764-709-11 CONNECTOR, FFC/FPC (LIF) 10P
< DIODE >
D801 8-713-102-80 DIODE 1T369-01-T8A
D802 8-719-420-51 DIODE MA729
D901 8-719-404-49 DIODE MA111
D903 8-713-102-80 DIODE 1T369-01-T8A
D904 8-719-421-27 DIODE MA728
D905 8-719-061-82 DIODE TLSU1002(TPX1,SONY)
D951 8-719-989-33 DIODE FC806
D952 8-719-941-86 DIODE DAN202U
D953 8-719-404-49 DIODE MA111
D954 8-719-058-86 DIODE PG1101H-TR
D955 8-719-404-49 DIODE MA111
< IC >
IC901 8-759-368-60 IC CM7012L3-T4
IC902 8-759-359-49 IC NJM3414AV(TE2)
IC951 8-759-060-94 IC MB3785APFV-G-BND-ER
< COIL >
L901 1-414-754-11 INDUCTOR 10uH
L902 1-414-753-91 INDUCTOR 4.7uH
L903 1-412-954-11 INDUCTOR 18uH
L905 1-414-754-11 INDUCTOR 10uH
L951 1-412-056-11 INDUCTOR CHIP 4.7uH
L952 1-412-058-11 INDUCTOR CHIP 10uH
L953 1-424-674-11 COIL, CHOKE 22uH
L954 1-409-536-41 COIL, CHOKE 150uH
L955 1-414-757-11 INDUCTOR 100uH
L956 1-414-757-11 INDUCTOR 100uH
L957 1-414-757-11 INDUCTOR 100uH
< TRANSISTOR >
Q901 8-729-402-42 TRANSISTOR UN5213
Q906 8-729-420-24 TRANSISTOR 2SB1218A-QRS
Q952 8-729-402-42 TRANSISTOR UN5213
Q955 8-729-823-84 TRANSISTOR FP102
Q956 8-729-804-41 TRANSISTOR 2SB1122-S
Q957 8-729-039-43 TRANSISTOR FP216-TL
Q958 8-729-420-24 TRANSISTOR 2SB1218A-QRS
< RESISTOR >
R901 1-216-843-11 METAL CHIP 68K 5% 1/16W
R902 1-216-843-11 METAL CHIP 68K 5% 1/16W
R903 1-216-841-11 METAL CHIP 47K 5% 1/16W
R904 1-216-841-11 METAL CHIP 47K 5% 1/16W
R905 1-216-839-11 METAL CHIP 33K 5% 1/16W
R906 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R907 1-216-840-11 METAL CHIP 39K 5% 1/16W
R908 1-216-821-11 METAL CHIP 1K 5% 1/16W
R909 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R911 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R913 1-218-891-11 METAL GLAZE 68K 0.50% 1/16W
R914 1-216-843-11 METAL CHIP 68K 5% 1/16W
R915 1-216-845-11 METAL CHIP 100K 5% 1/16W
R916 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R917 1-216-841-11 METAL CHIP 47K 5% 1/16W
R918 1-216-838-11 METAL CHIP 27K 5% 1/16W
R920 1-216-857-11 METAL CHIP 1M 5% 1/16W
R921 1-216-837-11 METAL CHIP 22K 5% 1/16W
R922 1-216-833-11 METAL CHIP 10K 5% 1/16W
R923 1-216-837-11 METAL CHIP 22K 5% 1/16W
R927 1-216-845-11 METAL CHIP 100K 5% 1/16W
R928 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
R931 1-216-839-11 METAL CHIP 33K 5% 1/16W
R932 1-216-839-11 METAL CHIP 33K 5% 1/16W
R933 1-216-840-11 METAL CHIP 39K 5% 1/16W
R934 1-216-845-11 METAL CHIP 100K 5% 1/16W
R936 1-216-842-11 METAL CHIP 56K 5% 1/16W
R940 1-216-833-11 METAL CHIP 10K 5% 1/16W
R945 1-216-841-11 METAL CHIP 47K 5% 1/16W
R947 1-216-817-11 METAL CHIP 470 5% 1/16W
R949 1-216-833-11 METAL CHIP 10K 5% 1/16W
R951 1-216-833-11 METAL CHIP 10K 5% 1/16W
R952 1-216-840-11 METAL CHIP 39K 5% 1/16W
R953 1-216-833-11 METAL CHIP 10K 5% 1/16W
R954 1-218-895-11 METAL GLAZE 100K 0.50% 1/16W
R955 1-218-885-11 METAL GLAZE 39K 0.50% 1/16W
R957 1-218-883-11 METAL GLAZE 33K 0.50% 1/16W
R959 1-218-871-11 METAL GLAZE 10K 0.50% 1/16W
R960 1-218-885-11 METAL GLAZE 39K 0.50% 1/16W
R961 1-216-864-11 METAL CHIP 0 5% 1/16W
R962 1-218-879-11 METAL GLAZE 22K 0.50% 1/16W
R963 1-218-871-11 METAL GLAZE 10K 0.50% 1/16W
R964 1-218-871-11 METAL GLAZE 10K 0.50% 1/16W
R965 1-218-883-11 METAL GLAZE 33K 0.50% 1/16W
R966 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R967 1-216-821-11 METAL CHIP 1K 5% 1/16W
R968 1-218-863-11 METAL GLAZE 4.7K 0.50% 1/16W
R970 1-216-851-11 METAL CHIP 330K 5% 1/16W
R971 1-216-857-11 METAL CHIP 1M 5% 1/16W
R972 1-216-853-11 METAL CHIP 470K 5% 1/16W
R973 1-216-851-11 METAL CHIP 330K 5% 1/16W
R974 1-216-817-11 METAL CHIP 470 5% 1/16W
R975 1-216-841-11 METAL CHIP 47K 5% 1/16W
R976 1-216-813-11 METAL CHIP 220 5% 1/16W
R977 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R978 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R979 1-216-810-11 METAL CHIP 120 5% 1/16W
R980 1-216-837-11 METAL CHIP 22K 5% 1/16W
R983 1-216-817-11 METAL CHIP 470 5% 1/16W
R988 1-216-840-11 METAL CHIP 39K 5% 1/16W
R989 1-216-845-11 METAL CHIP 100K 5% 1/16W
R991 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R992 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R993 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R994 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
PD-74
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifie.
