5-23
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< SWITCH >
S901 1-572-467-21 SWITCH, PUSH (MIRROR)(1 KEY)
S992 1-762-833-11 SWITCH, TACTILE (VOLUME –)
S993 1-762-833-11 SWITCH, TACTILE (VOLUME +)
S994 1-762-833-11 SWITCH, TACTILE (BRIGHT –)
S995 1-762-833-11 SWITCH, TACTILE (BRIGHT +)
< TRANSFORMER >
T951 1-431-292-21 TRANSFORMER, DC-DC CONVERTER
! T952 1-429-547-31 TRANSFORMER, INVERTER
A-7093-270-A PD-75 BOARD, COMPLETE (TRV14E)
**********************
(Ref.No.8,000 Series)
< CAPACITOR >
C1901 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C1903 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1904 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1907 1-162-924-11 CERAMIC CHIP 56PF 5% 50V
C1908 1-107-687-11 TANTAL. CHIP 3.3uF 20% 20V
C1909 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1910 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
C1911 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C1913 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1914 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1915 1-162-926-11 CERAMIC CHIP 82PF 5% 50V
C1916 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1917 1-164-363-11 CERAMIC CHIP 560PF 5% 50V
C1918 1-135-177-21 TANTALUM CHIP 1uF 20% 20V
C1919 1-135-177-21 TANTALUM CHIP 1uF 20% 20V
C1920 1-104-916-11 TANTAL. CHIP 6.8uF 20% 20V
C1921 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1922 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1923 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1924 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1925 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1951 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C1952 1-164-218-11 CERAMIC CHIP 180PF 0.25PF 50V
C1953 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C1954 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1955 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C1956 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C1957 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C1958 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C1960 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C1961 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C1962 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1963 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C1964 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C1965 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1966 1-164-346-11 CERAMIC CHIP 1uF 16V
C1967 1-104-911-11 TANTAL. CHIP 33uF 20% 10V
C1968 1-164-664-11 CERAMIC CHIP 0.033uF 10% 50V
C1969 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C1970 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C1972 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C1973 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C1974 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C1975 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C1976 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
! C1977 1-113-521-11 CERAMIC CHIP 12PF 10% 3KV
C1978 1-164-360-11 CERAMIC CHIP 0.1uF 16V
< CONNECTOR >
CN1802 1-770-629-21 PIN, CONNECTOR 12P
CN1803 1-691-388-11 CONNECTOR, FFC/FPC 24P
CN1804 1-764-708-21 CONNECTOR, FFC/FPC (LIF) 9P
CN1807 1-766-346-21 CONNECTOR, FFC/FPC 16P
CN1951 1-764-709-11 CONNECTOR, FFC/FPC (LIF) 10P
< DIODE >
D1902 8-713-102-80 DIODE 1T369-01-T8A
D1903 8-719-422-41 DIODE MA8051-L-TX
D1904 8-719-421-27 DIODE MA728
D1905 8-719-061-82 DIODE TLSU1002(TPX1,SONY)
D1951 8-719-989-33 DIODE FC806
D1952 8-719-941-86 DIODE DAN202U
D1953 8-719-404-49 DIODE MA111
D1954 8-719-058-86 DIODE PG1101H-TR
D1955 8-719-404-49 DIODE MA111
< IC >
IC1901 8-759-394-52 IC LZ95NA04
IC1902 8-759-359-49 IC NJM3414AV(TE2)
IC1951 8-759-060-94 IC MB3785APFV-G-BND-ER
< COIL >
L1901 1-414-754-11 INDUCTOR 10uH
L1902 1-414-754-11 INDUCTOR 10uH
L1903 1-216-295-91 CONDUCTOR, CHIP (2012)
L1904 1-412-957-11 INDUCTOR 33uH
L1951 1-412-056-11 INDUCTOR CHIP 4.7uH
L1952 1-412-058-11 INDUCTOR CHIP 10uH
L1953 1-424-674-11 COIL, CHOKE 22uH
L1954 1-409-536-41 COIL, CHOKE 150uH
L1955 1-414-757-11 INDUCTOR 100uH
L1956 1-414-757-11 INDUCTOR 100uH
L1957 1-414-757-11 INDUCTOR 100uH
< TRANSISTOR >
Q1901 8-729-402-42 TRANSISTOR UN5213
Q1904 8-729-230-63 TRANSISTOR 2SC4116-YG
Q1905 8-729-420-24 TRANSISTOR 2SB1218A-QRS
Q1952 8-729-402-42 TRANSISTOR UN5213
Q1955 8-729-823-84 TRANSISTOR FP102
Q1956 8-729-804-41 TRANSISTOR 2SB1122-S
Q1957 8-729-039-43 TRANSISTOR FP216-TL
Q1958 8-729-420-24 TRANSISTOR 2SB1218A-QRS
Q1962 8-729-420-24 TRANSISTOR 2SB1218A-QRS
PD-75PD-74
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifie.
To Next Page
