Sony CCD-TRV32 - Page 108

5-24
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< RESISTOR >
R1900 1-216-857-11 METAL CHIP 1M 5% 1/16W
R1903 1-218-891-11 METAL GLAZE 68K 0.50% 1/16W
R1904 1-216-845-11 METAL CHIP 100K 5% 1/16W
R1907 1-216-844-11 METAL CHIP 82K 5% 1/16W
R1908 1-216-844-11 METAL CHIP 82K 5% 1/16W
R1909 1-216-841-11 METAL CHIP 47K 5% 1/16W
R1910 1-216-836-11 METAL CHIP 18K 5% 1/16W
R1911 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R1912 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R1913 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1914 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1915 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R1916 1-216-837-11 METAL CHIP 22K 5% 1/16W
R1917 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1918 1-216-838-11 METAL CHIP 27K 5% 1/16W
R1919 1-216-857-11 METAL CHIP 1M 5% 1/16W
R1920 1-216-857-11 METAL CHIP 1M 5% 1/16W
R1921 1-216-843-11 METAL CHIP 68K 5% 1/16W
R1922 1-216-837-11 METAL CHIP 22K 5% 1/16W
R1923 1-216-843-11 METAL CHIP 68K 5% 1/16W
R1924 1-216-841-11 METAL CHIP 47K 5% 1/16W
R1925 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R1926 1-216-839-11 METAL CHIP 33K 5% 1/16W
R1927 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R1928 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1929 1-216-841-11 METAL CHIP 47K 5% 1/16W
R1930 1-216-839-11 METAL CHIP 33K 5% 1/16W
R1931 1-216-845-11 METAL CHIP 100K 5% 1/16W
R1932 1-216-842-11 METAL CHIP 56K 5% 1/16W
R1933 1-216-850-11 METAL CHIP 270K 5% 1/16W
R1934 1-218-883-11 METAL GLAZE 33K 0.50% 1/16W
R1935 1-218-879-11 METAL GLAZE 22K 0.50% 1/16W
R1936 1-216-841-11 METAL CHIP 47K 5% 1/16W
R1937 1-218-883-11 METAL GLAZE 33K 0.50% 1/16W
R1938 1-218-879-11 METAL GLAZE 22K 0.50% 1/16W
R1939 1-216-837-11 METAL CHIP 22K 5% 1/16W
R1940 1-216-864-11 METAL CHIP 0 5% 1/16W
R1943 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1945 1-216-841-11 METAL CHIP 47K 5% 1/16W
R1947 1-216-821-11 METAL CHIP 1K 5% 1/16W
R1949 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1951 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1952 1-216-840-11 METAL CHIP 39K 5% 1/16W
R1953 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1954 1-218-895-11 METAL GLAZE 100K 0.50% 1/16W
R1955 1-218-885-11 METAL GLAZE 39K 0.50% 1/16W
R1956 1-216-841-11 METAL CHIP 47K 5% 1/16W
R1957 1-218-883-11 METAL GLAZE 33K 0.50% 1/16W
R1958 1-216-864-11 METAL CHIP 0 5% 1/16W
R1959 1-218-871-11 METAL GLAZE 10K 0.50% 1/16W
R1960 1-218-885-11 METAL GLAZE 39K 0.50% 1/16W
R1961 1-216-864-11 METAL CHIP 0 5% 1/16W
R1962 1-218-879-11 METAL GLAZE 22K 0.50% 1/16W
R1963 1-218-871-11 METAL GLAZE 10K 0.50% 1/16W
R1964 1-218-877-11 METAL GLAZE 18K 0.50% 1/16W
R1965 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R1966 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R1967 1-216-821-11 METAL CHIP 1K 5% 1/16W
R1968 1-218-863-11 METAL GLAZE 4.7K 0.50% 1/16W
R1970 1-216-851-11 METAL CHIP 330K 5% 1/16W
R1971 1-216-857-11 METAL CHIP 1M 5% 1/16W
R1972 1-216-853-11 METAL CHIP 470K 5% 1/16W
R1973 1-216-851-11 METAL CHIP 330K 5% 1/16W
R1974 1-216-817-11 METAL CHIP 470 5% 1/16W
R1975 1-216-841-11 METAL CHIP 47K 5% 1/16W
R1976 1-216-813-11 METAL CHIP 220 5% 1/16W
R1977 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R1978 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R1979 1-216-810-11 METAL CHIP 120 5% 1/16W
R1980 1-216-837-11 METAL CHIP 22K 5% 1/16W
R1983 1-216-817-11 METAL CHIP 470 5% 1/16W
R1987 1-216-845-11 METAL CHIP 100K 5% 1/16W
R1991 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R1992 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R1993 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R1994 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
< SWITCH >
S1901 1-572-467-21 SWITCH, PUSH (MIRROR)(1 KEY)
S1992 1-771-029-21 SWITCH, TACTILE (VOLUME –)
S1993 1-771-029-21 SWITCH, TACTILE (VOLUME +)
S1994 1-771-029-21 SWITCH, TACTILE (BRIGHT –)
S1995 1-771-029-21 SWITCH, TACTILE (BRIGHT +)
< TRANSFORMER >
T1951 1-431-291-11 TRANSFORMER, DC-DC CONVERTER
! T1952 1-429-547-31 TRANSFORMER, INVERTER
A-7093-279-A PD-76 BOARD, COMPLETE
**********************
(TRV44/TRV52/TRV512)
A-7093-281-A PD-76 BOARD, COMPLETE (TRV44E)
**********************
(Ref.No.8,000 Series)
< CAPACITOR >
C806 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C808 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C810 1-107-685-11 TANTAL. CHIP 15uF 20% 6.3V
C811 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C812 1-104-912-11 TANTAL. CHIP 3.3uF 20% 6.3V
C813 1-135-333-11 TANTAL. CHIP 1uF 20% 16V
C814 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C816 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
(TRV44E)
C818 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C820 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(TRV44E)
C822 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C823 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(TRV44E)
C825 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C826 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(TRV44E)
C827 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(TRV44E)
PD-75 PD-76
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifie.
