5-25
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C828 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C829 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C832 1-162-926-11 CERAMIC CHIP 82PF 5% 50V
(TRV44E)
C835 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
(TRV44E)
C835 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
(TRV34/TRV44/TRV52/TRV512)
C836 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
(TRV44E)
C836 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
(TRV34/TRV44/TRV52/TRV512)
C837 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
(TRV44E)
C837 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
(TRV34/TRV44/TRV52/TRV512)
C838 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C839 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C840 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C841 1-135-214-21 TANTAL. CHIP 4.7uF 20% 20V
C842 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C844 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C900 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C901 1-104-916-11 TANTAL. CHIP 6.8uF 20% 20V
C902 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C903 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C904 1-107-685-11 TANTAL. CHIP 15uF 20% 6.3V
C905 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C906 1-107-686-11 TANTAL. CHIP 4.7uF 20% 16V
C909 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C910 1-164-363-11 CERAMIC CHIP 560PF 5% 50V
C911 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C912 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C913 1-162-926-11 CERAMIC CHIP 82PF 5% 50V
C914 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C915 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C916 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C917 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C918 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C919 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C920 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C951 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C952 1-164-218-11 CERAMIC CHIP 180PF 0.25PF 50V
C953 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C954 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C955 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C956 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C957 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C958 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C959 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C960 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C961 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C962 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C963 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C964 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C965 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C966 1-164-346-11 CERAMIC CHIP 1uF 16V
C967 1-104-911-11 TANTAL. CHIP 33uF 20% 10V
C968 1-164-664-11 CERAMIC CHIP 0.033uF 10% 50V
C970 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C971 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C972 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C973 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C974 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C975 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C976 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
! C977 1-113-521-11 CERAMIC CHIP 12PF 10% 3KV
C978 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C979 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
< CONNECTOR >
CN801 1-770-627-21 PIN, CONNECTOR 10P
CN802 1-770-629-21 PIN, CONNECTOR 12P
CN803 1-573-366-21 CONNECTOR, FFC/FPC 26P
CN804 1-764-708-21 CONNECTOR, FFC/FPC (LIF) 9P
CN805 1-764-709-11 CONNECTOR, FFC/FPC (LIF) 10P
CN808 1-573-929-11 CONNECTOR, FFC/FPC (ZIF) 20P
< DIODE >
D801 8-713-102-80 DIODE 1T369-01-T8A (TRV44E)
D901 8-719-404-49 DIODE MA111
D903 8-713-102-80 DIODE 1T369-01-T8A
D904 8-719-421-27 DIODE MA728
D905 8-719-061-82 DIODE TLSU1002(TPX1,SONY)
D951 8-719-989-33 DIODE FC806
D952 8-719-941-86 DIODE DAN202U
D953 8-719-404-49 DIODE MA111
D954 8-719-404-49 DIODE MA111
< IC >
IC801 8-752-067-59 IC CXA1785R-T4
IC802 8-759-355-92 IC AK9813AF-E2
IC900 8-759-073-95 IC SED1510FOC-T4
IC901 8-759-443-40 IC CM7013L1-T4
IC902 8-759-359-49 IC NJM3414AV(TE2)
IC951 8-759-060-94 IC MB3785APFV-G-BND-ER
< COIL >
L803 1-414-755-11 INDUCTOR 22uH
L804 1-412-956-21 INDUCTOR 27uH (TRV44E)
L805 1-414-754-11 INDUCTOR 10uH
L901 1-414-754-11 INDUCTOR 10uH
L902 1-216-295-91 CONDUCTOR, CHIP (2012)
L903 1-414-754-11 INDUCTOR 10uH
L904 1-412-951-11 INDUCTOR 10uH
L951 1-412-056-11 INDUCTOR CHIP 4.7uH
L952 1-412-058-11 INDUCTOR CHIP 10uH
L953 1-424-674-11 COIL, CHOKE 22uH
L954 1-409-536-41 COIL, CHOKE 150uH
L955 1-414-757-11 INDUCTOR 100uH
L956 1-414-757-11 INDUCTOR 100uH
L957 1-414-757-11 INDUCTOR 100uH
PD-76
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifie.
