DCR-PC101/PC101E
5-41
8. White Balance Adjustment (PD-166 board)
Correct the white balance.
If deviated, the LCD screen color cannot be reproduced.
Mode CAMERA
Subject Not required
Measurement Point Check on LCD screen
Measuring Instrument
Adjustment Page C
Adjustment Address 67, 68
Specified Value LCD screen must not be colored
Note 1: Check that the data of page: 0, address: 10 is “00”.
Note 2: Check the white balance only when replacing the fol-
lowing parts. If necessary, adjust them.
1. LCD panel
2. Light induction plate
3. IC801
Adjusting method:
Order Page Address Data Procedure
1 0 01 01
2 C 67 7D Press PAUSE button.
3 C 68 65 Press PAUSE button.
4
Check that the LCD screen is
not colored. If not colored,
proceed to step 6.
5C
Change the data so that the
LCD screen is not colored.
(Note 3)
6 0 01 00
Note 3: To write in the non-volatile memory (EEPROM), press
the PAUSE button each time to set the data.
67
68
To Next Page
